         Current Location: Home >> Solar Rack >> SolarRoof PV Mounting
 The SolarRoof PV Mounting System has been developed as a universal framed PV module mounting system for  pitched roof and flat roof installations. The innovative and patented aluminum base rails,Z modules and rail extension  technology eliminate the need for onsite cutting and enable quick and easy field PV module installations. For the various  roofs,we design the relative roof hook to make it easy mounted. For example:the SS Roof hook is designed to fix with the  tile roof, while the L feet is designed for the metalroof,tilt legs are designed for the flat roof,etc.
SolarRoof-PV-Mounting-
 Features
Installation Site : Pitched Roof or Flat Roof
Roof Cladding : Suitable for most type of cladding
Roof Slop : Up to 60°
Building Height : Up to 20m
Wind Load : 60m/s
Snow Load : 1.4KN/m 2
PV Modules : Framed
Module Orientation : Vertical or horizontal
Module Width : Any
Standard : AS/NZS 1170 and other international standards
Support Rail : Extruded aluminum
Color : Natural
Warranty : 10 years durability on material
  •      Easy Installation
  •      Diversified Application
  •      Universal Compatibility
  •      Choice Quality
  •      10-Year Guarantee
  •      Maximum Lifespan
  •      100% recyclable, environment friendly
mail-us
The ezRack can be mounted paralleled or pitched with roof.Please review the following product:
  • With Fixed Angle Tilt Legs (30 Degree)
  • With Fixed Angle Tilt Legs (10-15 Degree)
  • With Fixed Angle Tilt Legs (30-60 Degree)
